Multihole pressure probe-DPS—L
Product Description
8 channel differential pressure sensor for CAN bus with Scanivalve connector
Key Features
8 channel differential pressure sensor for CAN bus
with Scanivalve connector
Information & Quotation
Request a quotation today or leave your details to recieve moreinformation from one of our experts
Specification
| Parameters | |
| Range | ±50 to ±1000 mBars ±0.7 to ±15 PSI |
| Sensing Element | Piezo Resistor Battery |
| Accuracy | ±0.5%FS |
| non-linearity | ±0.7%FS |
| With Low Bias Voltage Error | ±0.5%FS |
| Sensitivity Drift | 0.50% |
| Sampling Frequency | 200Hz |
| Output | 2 bytes per channel |
| Transmission Rate | 125k to 1Mbps |
| Data Frequency | 1 to 200hz or trigger |
| Supply Voltage | 6 to16V |
| Supply Current | 30mA |
| Dimensions | 89X35X14mm |
| Materials | Aluminum |
| Weight | 20g |
| Under Attack | 500g |
| Operating Temperature Range | 5~+85°C |
| Storage Temperature Range | -40~+125°C |
